Model

BF1700-I

BF1700-II

BF1700-III

BF1700-IV

BF1700-V

BF1700-VI

Chamber size

（WxDxH）mm

100x120x100

150x150x150

200x200x200

200x300x200

250x320x250

300x400x300

Outer size（WxDxH）mm

383 x432x660

510x560x870

600x620x920

600x693x920

610 x730x970

700x840x1500

Max temperature

1700℃

Working temperature

1600℃

Power supply

220V/2KW

220V/4KW

220V/5KW

220V/6KW

220V/7KW

380V/15KW

Heating element

MoSi2 rod

Chamber material

Polycrystalline inorganic alumina ceramic fiber material prepared by wet vacuum filtration

Temp.Precision

±1℃

Termocouple

B Type termocouple

Temperature controller

Intelligent microcomputer PID temperature control instrument, SSR control, PID parameter self-tuning function; programmable 30 program segments, program temperature rise, program heat preservation, program cooling

Heating rate

1-15℃/min free adjustment

Furnace structure

Furnace temperature control integrated structure

Equipment protection

Modular control, sound and light alarm signal will be sent out for over temperature and broken coupler in the working process, and the protection action will be completed automatically

Safety protection

The equipment is equipped with a circuit breaker, which will automatically pop open in case of short circuit leakage, which can protect the safety of equipment and operators

Optional

1. Optional exhaust chimney for evacuation of volatile substances  2. Optional corundum crucible, furnace floor, shed board and other kiln furniture 3. Optional material recorder for online recording of temperature curves

Competitive Advantage

1、Factory direct delivery

2、Quality assurance

3、Best price

4、Compact in size

5、Complete specifications

6、Service Assurance
